適用范圍Application：

適用于紡織品、服裝、床上用品、睡袋、室內裝飾物、薄膜、涂層材料、泡沫、皮革、多層織物組合的紡織品等平面材料的熱阻和濕阻測試。檢測精度遠高于標準，滿足測定紡織品生理舒適性方面熱濕性能指標的理想儀器。

It is suitable for thermal resistance and evaporative resistance test of flat materials such as clothing, bedding, sleeping bags, interior decorations, films, coating materials, foams, leathers, and multi-layer fabrics. The detection accuracy is much higher than the standard, and it is the ideal instrument for measuring the thermal and evaporative resistance performance of textiles.

?

方法標準Standard：

GB/T11048-2008 ?ISO11092 ?ASTM F1868(A-E)

產品特點Characteristics：

1、并采用高精度溫度傳感器，大大提高了儀器的測試精度、重復性和穩定性.?

With the high-accuracy temperature sensor, which greatly improves the testing accuracy, repeatability and stability.

2、試驗板采用特制不銹鋼材料粉末冶金做成的微孔多孔板。在20℃環境下，以波長范圍8um到14um 的光束垂直照射于該試驗板表面并以半球反射的方式，測得該試驗板表面的輻射系數高于0.4。相比其他材料制成的試驗板，避免了長時間濕阻試驗后產生的生銹、銅銹（銅綠）等問題而堵住試驗板

The testing board is made of micro porous plate of special stainless steel material powder metallurgy. The emissivity of the plate surface is measured to be higher than 0.4 at a temperature of 20℃ by irradiating perpendicularly with a light beam in the wavelength range of 8 μm to 14 μm and reflected as a hemisphere. Compared to the plates made of other materials, our instrument will avoid the rust, copper rust (bluish green) and other problems blocking the test plate after the long time evaporative resistance test

3、采用微電腦控制和數據處理器，可直接測定并計算試樣的各項性能。（熱阻、濕阻、透濕率、透濕指數、保溫率、傳熱系數、克羅值）無需人工計算.

Use microcomputer controlling and data processor, which can directly measure and calculate the performance of the specimen without manual calculation, such as thermal and evaporative resistance, evaporative permeability, evaporative permeability index, thermal insulation rate, heat transfer coefficient and crow value

4、采用大屏幕彩色液晶觸摸屏顯示，可貯存所有測試過程中數據和*終統計結果，提供查詢.

A large color touch screen can store all the testing data and final statistical results for providing inquiries.

?

技術參數Technical Parameter：

1.熱阻Thermal Resistance

（1）測試范圍Testing Range：0 ~2.000m2 ?K/W；

（2）分辨率Resolution Ratio：0.0001m2 ?K/W；

（3）重復性誤差Testing Repeatability Error≤±2.5%,出廠控制Factory Control±2%；

2.濕阻Moisture resistance

（1）測試范圍Testing Range： 0~1000 m2 ?Pa / W；

（2）分辨率Resolution Ratio：0.01m2 ? Pa/W；

（3）重復性誤差Testing Repeatability Error≤±2.5%,出廠控制Factory Control±2%。

3.試驗板溫度調節范圍Temperature range of the testing board：20～50℃；

4.試驗板中心上方15mm處空氣的速度Air speed at 15mm above the center of the testing board：1（or 0.5 or 1.5）m/s optional、±0.05m/s；

5.小氣候室要求Microclimate Room request：

20℃±0.1℃分辨率Resolution Ratio：0.01℃ 、65%±3%分辨率Resolution Ratio：0.01%（熱阻Thermal Resistance）

35℃±0.1℃分辨率Resolution Ratio：0.01℃ 、40%±3%分辨率Resolution Ratio：0.01%（濕阻Moisture resistance）；

6.平臺可升降范圍（試樣厚度）The lifting range of the testing board(specimen thickness)≤ 70mm；

7.加熱板溫控精度Temperature controlling Accuracy of the heating plate：±0.1℃；

8.試驗板尺寸Testing Board Size：200×200；

9.試樣尺寸Specimen Size：350×350mm；

10.外型尺寸External Dimension：1000×770×1800mm；

11. 重量Weight：400Kg；

12. 電源Power：AC220V±10%,4000W。
