無錫市德潤輕工機械廠
品類 | 轉鼓 | 品牌 | DESH |
---|---|---|---|
型號 | 不銹鋼控溫四,六轉鼓 |
性能:
*采用熱泵循環加熱,停鼓時能加熱恒溫。
*無級變速,速度快慢可調(0-30轉分)
*自動加溫,恒溫,溫度控制正確(0-70℃±1℃)
*全新快啟式鼓門,操作方便,并可水洗
*加熱液和鼓內液體分離,清洗徹底,無殘液和廢渣
*設工作時間總定時,定時正反轉動,調節時間(0-30)分,也可單方向轉動
*有多組溫控儀分別控制小鼓溫度
*每小鼓設手動離合器可隨時停其一鼓
properties:
* using heat pump cycle heating, stop when heating temperature can drum.
* stepless speed, speed, speed adjustable (0 to 30 turn points)
* automatic constant temperature, heating, temperature control right (0-70℃±1℃)
* new fast rev. type drum door, convenient operation, and can be washed
* heating fluid and inside the drum liquid separation, cleaning thoroughly, no residual liquid and waste residue
* a total of timing, timing work time of positive and negative rotation, the regulating time (0 to 30) points, also can a single direction
* with multiple temperature control instrument control temperature respectively small drum set
* every old fashioned-like drum set manual clutch may at any time stop one drum
主要技術參數:
型號model | gi350*160*4 | gi350*160*6 | gi350*180*4 | gi350*180*6 | gi450*200*4 |
規格size(mm) | φ350*160 | φ350*160 | φ350*180 | φ350*180 | φ450*200 |
裝皮量(kg)max loading capacity | 1 | 1.2 | 1 | 1.2 | 2 |
轉速speed | 0~35 | 0~35 | 0~35 | 0~35 | 0~30 |
電機功率motor power(kw) | 0.37 | 0.37 | 0.75 | 0.75 | 0.75 |
電加熱功率electric heating power(kw) | 4 | 6 | 4 | 6 | 4 |
控溫范圍control temperature range | 0-70℃ | 0-70℃ | 0-70℃ | 0-70℃ | 0-70℃ |
重量weigth(kg) | 180 | 200 | 220 | 230 | 280 |
