熱轉移印花機原理：

  使用花紙的染料產生升華作用，轉移到被印織物上，在被印織物上形成所需的各種圖案。
   本廠引進意大利技術并根據市場需求不斷專研、改進、開發zy系列轉移印花機，本機配套自動控邊進布器和自動驗卷機，使整個印布過程更為方便。

transfer printing theory：

  transfer printing is a kind of new technology which gradually rising up wordwide in recent several years.*****,for making the transfer printing paper of kinds of patterns,print the required patterns onto the special paper with special dye(watersoluble or oil soluble)by advanced printing technology.anadthen,on the transfer printing machine,close the pattern printed side of the transfer printing paper with the textile which will be printed,through the action of heat and pressure,induce the sublimation of the dye which absorbed by the printing paper,so the dye is transferred to the texfile be printed,kinds of required patterns are formed on the prnted textile.
  our factory has fetched in the tcchnology from taiwan,and according to the requirements of the market,also has kept on making dive and improvement to develop the heat-transfer printing machine fo zy series.this machine has self-contained automatic selvage-control entrance keeper and automaticinspecting and rolling machine,which make the whole printing process more convenient.

產品特點：
1.整機式主機機架，堅固不易變形、轉動，導布機械設計靈巧，操作簡便。機器的主要部件主滾筒內部設有內循環系統。通過電加熱、油導熱，使滾筒表面溫度控制在±1℃以內。
2.采用pid自動溫控儀，自動調節保溫電流控制精度高。
3.手動退毯帶裝置，升降溫時脫開毯帶，延長毯帶使用壽命。
4.本機設有布邊紙及墊紙裝置，降低毛毯污染，減少清洗次數。
5轉印后之成品免處理，花樣色彩鮮明，柔軟光麗，保持色質經久不變。
6.印花速度控制采用無級調速。
7.溫度范圍：室溫300℃

product character：

1.the moreblock type principal machine frame is firm end cannot be deformed easy,the menhenicaj design of rotation and cloth guide is clever and convenient for operation.there is an intornal circulation system in the home roll.which is the mainpart ofthe machine,sothe surfacetempamtureofthe roll can be controlled within±1℃through electric-heating and oil-heat-transfeming.
2.adopt pid automatic temparature-control-instument,which can automalti-cally adlust the elentrlc current of insulation woork,and bring high accuracy of control.
3.the handoperated blanket-belt reversal device can make the blanket-belt runoff when heating up or cooling down,so that can prolong the operating life of the blanket-belt.
4.there is a papar-backing device for selvage-paper,which can decrease the pollution of the blanket,and reduce the cleansing time.
5.the finished transfer-printed product needs no treatment,so it has pattems of vivid color,and it is soft and bright and beautiful,and its color is durable.
6.adopt stepless speed regulation to control printing speed.
7.remparature range:roomtemperature of 300℃

參數：滾筒直徑以及幅寬：

400mmx1.7m(有效1.6）

500mmx1.7m(有效1.6m)

600mmx2.3m(有效2.2m)

600mmx1.2m(有效1.1m)

750mmx1.2m(有效1.1m)

800x2.8(有效2.7m)

1mx2.3m(有效2.2m)

1.2mx3.6(有效3.4m)

 備注:本廠所產的熱轉移印花機的 滾筒直徑與幅寬都是跟據客戶的要求來定制的.
